System Specifications

Operating System:
Windows 10 Pro 64-bit, Windows 11 Pro 64-bit

Processor and Speed:
Intel Core i5/7 (Haswell or newer), AMD Ryzen 5/7, 4 processing cores or more, 2.5 GHz or more
(Recommended: Intel Core i7 or Xeon, AMD Ryzen 7, 4 processing cores or more, 2.9 GHz or more)

Memory (RAM):

• Reconstruction density normal:

  • 16 GB for <30 images per model

  • 32 GB for 30–500 images per model

  • 64 GB for >500 images per model

• Reconstruction density high:

  • 32 GB RAM for <30 images per model

  • 64 GB RAM for >30 images per model

• For FragMetriX application: 64 GB RAM strongly recommended

Storage:
256 GB (recommended 1 TB or more); solid state drive (SSD) recommended

3D Graphics Card (GPU):

• OpenCL 1.2 is mandatory

• Dedicated GPU with 4 GB RAM is mandatory for feasible performance

• 6 GB RAM or more is highly recommended

• AMD graphics cards are not supported

• Systems without dedicated GPU allow processing but performance may be heavily compromised

Examples:
NVIDIA GeForce RTX 3060, NVIDIA RTX A3000, NVIDIA Quadro P3000, NVIDIA RTX A4000, NVIDIA Quadro P4000

Other Requirements:

• USB type A port (2.0, 3.0)

• Display: 1920×1200, 32-bit colour screen

• Network: Ethernet or WLAN

• Software installation requires administrator privilege
